USER'S MANUAL
General instructions for use
I-Max Touch (110-120V) (Rev. 0)
48
6.5.2.1 Anatomic exposure
Select the type of patient with the Adult/Child key (7).
Select the type of build with the Size (8) key (small - medium - large).
On the basis of these selections, the display will visualise the kV and mA
settings as in the table.
Exposure values in PAN mode
Adult Patient
(13.8 seconds)
Child Patient
(13.4 seconds)
kV mA kV mA
Small 68 6 64 6
Medium 72 6 66 6
Large 74 6 68 6
Table 2
Select the type of biting with the key "Type of Biting Selection"
(9) .
NOTE:
The type of biting does not affect the kV and mA values, but it affects the
position of the focus layer, by adapting the rotation movement to the
patient's anatomy.
*
