USER'S MANUAL
Introduction
(Rev. 0) I-Max Touch (110-120V)
1
1. INTRODUCTION
NOTE:
The present manual is updated for the product it is sold with, in order to
guarantee an adequate reference to use the product properly and safely.
The manual may not reflect changes to the product that do not affect
operating modes or safety.
The I-Max Touch, produced by Owandy, is an X-ray device for the
radiographic analysis of the maxillo-facial complex.
The basic version of the I-Max Touch performs Panoramic, Emi-
panoramic, Reduced dose Panoramic, Frontal dentition, Improved
orthogonality Panoramic, Sinus and TMJ examinations of the maxillo-
facial complex.
The following options are available, and must be ordered separately:
• DIGITAL CEPH; it allows the execution of the following examinations,
all available in high resolution and normal resolution (high speed)
modality:
- CEPH exam in different formats
- CARPUS exam.
The aim of this publication is to instruct the user on the safe and
effective use of the device.
This Manual is limited to the description of the X-ray device; instructions
on the Digital Acquisition System are given in the relevant Manuals,
supplied with the Direct Digital Sensor.
The device must be used complying with the procedures described and
never be used for purposes different from those herewith indicated.
Please read this manual thoroughly before starting to use the unit; it is
advisable to keep the manual near the device, for reference while
operating.
The I-Max Touch is an electro-medical device and it can be used only
under the supervision of a physician or of highly qualified personnel,
with the necessary knowledge on X-ray protection.
The user is liable as concerns legal fulfilment related to the installation
and the operation of the device.
*
