Owandy I-Max Touch - Anatomic; Manual Exposure

USER'S MANUAL
General instructions for use
I-Max Touch (110-120V) (Rev. 0)
72
6.7.1 Anatomic / Manual Exposure
NOTE:
If the previous exam was carried out manually, just press the key "Size
Selection" (8) or the key "Examination Mode Selection"
(10) .
After setting the machine, it is possible to choose between the following
two operating modes:
• ANATOMIC: with the values of kV and mA programmed on the basis
of the type of patient and the size.
• MANUAL: with the possibility to vary the kV and mA values already
set.
NOTE:
In the manual mode, the "Anatomic/Manual mode" (13) indicator
displays "M" to indicate the manual mode; it is possible to use
key (7) to change from Adult to Child.
*
*
