USER'S MANUAL
General instructions for use
I-Max Touch (110-120V) (Rev. 0)
60
6.6.2.1 Anatomic exposure
Select the type of patient with the Adult/Child key (7).
Select the type of build with the Size (8) key (small - medium - large).
On the basis of the selections made, the display will visualise the kV and
mA settings as in the table.
Exposure values in TMJ examination (9.7 sec)
Examination
Adult Child
TMJ mouth closed/open
kV mA kV mA
Small 68 6 62 6
Medium 72 6 64 6
Large 76 6 66 6
Table 3
The time (9.7 sec.) refers to the sum of the four exposures (2 closed
mouth exposures and 2 open mouth exposures).
