USER'S MANUAL
General instructions for use
I-Max Touch (110-120V) (Rev. 0)
52
7. At this point, the patient must move his feet towards the column,
making sure to keep his head within the pre-aligned anatomical
references. In this way, you will have a greater extension of the spine
in the cervical area, improving the darkening of the X-ray in the
apical area of the incisors, and avoiding the collision of the tube-head
with the patient's shoulders. Check that the Frankfurt plane is still
horizontal.
8. Close the temple clasps (Figure 9) to help the patient keep a correct
position; bring also the forehead support close to the patient's
forehead and ensure that, in this phase, the patient has not changed
position.
9. Press the key "Patient Entrance" (6) to confirm the
parameters. The luminous centring devices switch off and the
rotating arm goes to its examination start position.
Once alignment has been completed, the following message will be
displayed:
x x k V x x m A x x . x s
S T A R T E X A M
x = value defined by the settings
The green LED "Ready for X-ray" lights up to indicate that pressing
the X-ray button once more will start the radiation phase.
10. Ask the patient to: keep the lips closed, bring the tongue
towards the palate, keep perfectly still and do not look at the
rotating arm during the movements.
