USER'S MANUAL
General instructions for use
(Rev. 0) I-Max Touch (110-120V)
65
NOTE:
The I-Max Touch assumes that the digital sensor is ready: if this is not
the case, the following error message will be displayed:
D I G I T A L S E N S O R
I S N O T R E A D Y
Refer to the Manual of the Digital Acquisition System to correct the
situation.
To reset the message on the I-Max Touch, press key .
NOTE:
The rotation of the arm and the emission of the X-rays will start with a
delay of 2 seconds from pressing the X-ray button. As the X-ray button
is a "dead man's switch", it is necessary to keep it pressed until the
end of the exposure.
The X-ray emission to the central part of the dental arch is suspended
during the examination phase, so the relative signals (sound and visual)
are therefore also suspended.
2. Once the exposure is completed, the system will carry out a short
return rotation and the following message will be displayed:
P A T I E N T E X I T
P R E S S > 0 <
It will then be possible to set up the system for the open mouth
examination, keeping the patient in position or releasing him from
the working area.
3. Press the key "Patient Entrance" (6) . The machine will
reposition itself back to the starting position displaying the message:
P L E A S E W A I T . . .
The end of the movement, the display will show the message:
I N S T R U C T P A T I E N T
T O O P E N M O U T H !
*
*
