USER'S MANUAL
General instructions for use
I-Max Touch (110-120V) (Rev. 0)
78
NOTE:
The I-Max Touch assumes that the digital sensor is ready: if this is not
the case, the following error message will be displayed:
D I G I T A L S E N S O R
I S N O T R E A D Y
Refer to the Manual of the Digital Acquisition System to correct the
situation.
To reset the message on the I-Max Touch, press key .
NOTE:
The rotation of the arm and the emission of the X-rays will start with a
delay of 2 seconds from when the X-ray button is pressed. As the X-ray
button is a "dead man's switch", it is necessary to keep it pressed
until the end of the exposure.
During the examination, the emission of rays in correspondence with the
central part of the dental arch is suspended; the relative signals (sonant
and visual) are also suspended.
2. Once the exposure is completed, the system will rotate back. When it
has completed this manoeuvre, the display shows the message:
P A T I E N T E X I T
P R E S S > 0 <
and it will be necessary to free the patient from the positioning
device.
3. Press the key "Patient Entrance" (6) . The machine will
reposition itself back to the starting position displaying the message:
P L E A S E W A I T . . .
At the end, the following message is displayed:
x x k V x x m A 9 . 4 0 s
S I N U S
x = value defined by the settings
that shows the values set for that last exposure. A new exposure can
now be made.
*
*
