13
Figure 1-3: Labels on the front panel and removeable cover of the combiner
LASER APERTURE LABEL
This label indicates the aperture from where the laser emission will
propagate. There is one label aside each aperture.
LASER CLASS LABEL
This label indicates the class of the combiner as a laser
source, and warns about the potential hazards in case
of exposure to the radiation.
