32
Each of these laser sources can either be:
- A LaserBoxx model (LBX, LCX, LPX, LSX),
- A third-party source (Coherent OBIS™, CNI MGL series, and others)
Each of them can be optionally linked to either an AOM or an MPA for modulation or power adjustment.
Here is an example of how each of these components are located inside an L6Cc combiner:
Note that the laser sources are numbered starting from the farthest slot from the exit aperture. Refer to the
Manufacturing Test Report of your combiner to locate each laser source.
4-2 How to operate the combiner: the essential
functions
NOTE
Most of the procedures described in this chapter rely on using Oxxius’ graphical user interface (GUI); refer to
chapter 3-4 for a description of this GUI.
