67
- Mobile flange: this flange constitutes the repositionable part of the RFC. In can be put off when the
release lever is in “off” position.
- Lock screw: this screw, when secured, prevents the RFC mobile flange from being accidentally disunited
from the combiner.
- Lever: use this lever to lock or release the mobile flange. Note the two positions of the lever as in the
following picture:
- Cap cover: this cap prevents dust from contaminating the coupler as the RFC is detached.
INSTALLATION
This module is fixed at the output of the combiner, pre-aligned with the combined beam.
