Section 300-Installation Chapter 5. Peripheral Equipment
DBS-2.3/9.2-300 DBS Manual - Revised April 2000 5-7
Figure 5-3. RAI connection
RAI-A(VB-43706): 300 bps
or
RAI-B(VB-43707): 300 or 1200 bps
SCC-B Car
d
(VB-43421)
Hooks
OFF
ON
SW 4
J
1
124816
7dBm
RAI-B C a rd
Setsattenuation level.
The attenuation isthe
sum of the "ON"settings.
LeaveJ1Closed
(300 BPS/1200
BPS M ode)
