Panasonic CPC-EX - Figure 4-18. Trunk or Extension Expansion

Section 300-Installation Chapter 4. Trunks and Lines
DBS-2.3/9.2-300 DBS Manual - Revised April 2000 4-45
Figure 4-18. Trunk or extension expansion
See Table 4-3 on page 4-6 for pinout and trunk number information for the
trunk
expansion connector.
CN11
CN1CN1
CN15
Screw
Motherboar
d
FG
Term inal
Fasten
withScrew
CN15
CN2
(On the
expansion
connector)
Right Side ViewFront View
Ground
Cable
CO Lines or
Extensions
Trunk or
Extension
Expansion
C onnector
