Panasonic CPC-EX - Table 4-16. T1 and Analog Trunk Assignments, DBS 96 + DBS 72 (24-Channel T1 in the Master; 24-Channel T1 in the Slave)

Chapter 4. Trunks and Lines Section 300-Installation
4-18 DBS Manual - Revised April 2000 DBS-2.3/9.2-300
Table 4-16. T1 and analog trunk assignments, DBS 96 + DBS 72 (24-channel T1 in the master; 24-
channel T1 in the slave)
Trunk Number Master Cabinet Slave Cabinet
1 Analog trunk 1
↓↓ N/A
8 Analog trunk 8
9 T1 channel 24
↓↓ N/A
16 T1 channel 17
17 T1 channel 16
↓↓ N/A
24 T1 channel 9
25 T1 channel 8
↓↓ N/A
32 T1 channel 1
33 T1 channel 24
↓Ν/Α ↓
40 T1 channel 17
41 T1 channel 16
↓Ν/Α ↓
48 T1 channel 9
49 T1 channel 8
↓Ν/Α ↓
56 T1 channel 1
