Section 300-Installation Chapter 3. Cabinet Installation
DBS-2.3/9.2-300 DBS Manual - Revised April 2000 3-13
Key Phone Wall Mounting
DBS key phones can be modified for wall mounting by reversing the wall-
mount adaptor on the bottom of the phone. The wall-mount adaptor includes a
small hole for attaching the phone to a screw inserted in the wall.
1. Place the bottom edge of the telephone on a desk or other hard surface.
2. Press the wall-mount adaptor down until it detaches from the phone
(Figure 3-11).
Figure 3-11. Wall-mount adaptor removal
Wall-Mount
Adaptor
