Chapter 7. Specifications
Section 300-Installation
7-4 DBS Manual - Revised April 2000 DBS-2.3/9.2-300
Environmental Requirements
Table 7-4. Temperature and humidity requirements
Table 7-5. Dimensions and weight, single-cabinet systems and phones
Table 7-6. Dimensions for two-cabinet systems
Environmental Conditions Requirements
Temperature 32 to 104° F (0 to 40° C)
Relative Humidity 30 to 90%
Physical
Characteristics
DBS 40 DBS 72 DBS 96
Dimensions (H x W x D in inches)
Cabinet 21 x 15 x 9.35 21 x 19.5 x 9.4 21 x 19.5 x 9.4
VB-43225 4 1/8 x 7 3/8 x 9
Other key phones 3 3/4 x 7 3/8 x 9
DSLT 3 1/8 x 7 3/8 x 9 1/8
DSS/72 3 1/2 x 7 1/2 x 9
EM/24 3 3/13 x 3 1/8 x 8 3/8
Weight (lbs)
Cabinet 53 65 68
VB-43225 2.3
Other key phones 2.2
DSLT 1.6
DSS/72 1.6
EM/24 .9
Cabinet Installation DBS 40 + DBS 40 All Other Combinations
Cabinets installed one above the other
(10 in. between)
52 x 15 x 9.35 52 x 19.5 x 9.4
