Chapter 4. Trunks and Lines
Section 300-Installation
4-40 DBS Manual - Revised April 2000 DBS-2.3/9.2-300
4. Use a standard 50-pin cable to connect the extensions from the MDF to
the appropriate extension connector. (Refer to Tables 4-20 through 4-22
for extension pinouts.)
5. If you are installing a DBS 40 system, attach the EMI filter to the
amphenol cable as shown in Figure 4-15.
Figure 4-15. EMI filter installation (DBS 40 only)
EM I
Filter
31/2"
To Next Page
