6-20
Operation mode
Incremental <Relative value control>
Outputs the pulses set with the target value.
Selected
Mode
Target
value
CW/CCW
Pulse and direction
forward OFF/
reverse ON
Pulse and direction
forward ON/
reverse OFF
HSC counting
Method
Positive
Pulse output
from CW
Pulse output when
direction output is
OFF
Pulse output when
direction output is
ON
Incremental
Negative
Pulse output
from CCW
Pulse output when
direction output is
ON
Pulse output when
direction output is
OFF
Decremental
Example:
When the current position (value of elapsed value area) is 5000, the pulse of 1000 is output from CW by
executing the pulse output instruction with the target value +1000, and the current position will be 6000.
Absolute <Absolute value control>
Outputs a number of pulses equal to the difference between the set target value and the current value.
Selected
Mode
Target
value
CW/CCW
Pulse and direction
forward OFF/
reverse ON
Pulse and direction
forward ON/
reverse OFF
HSC counting
method
Target value
greater than
current value
Pulse output
from CW
Pulse output when
direction output is
OFF
Pulse output when
direction output is
ON
Incremental
Target value
less than
current value
Pulse output
from CCW
Pulse output when
direction output is
ON
Pulse output when
direction output is
OFF
Decremental
Example:
When the current position (value of elapsed value area) is 5000, the pulse of 4000 is output from CCW
by executing the pulse output instruction with the target value +1000, and the current position will be
1000.
Home return
When executing the F171 (SPDH) instruction, the pulse is continuously output until the home input (X2
or X5) is enabled.
To decelerate the movement when near the home position, designate a near home input and set bit 4
of special data register DT90052 to off on off.
The deviation counter clear output can be output when home return has been completed.
JOG operation
Pulses are output from the specified channel while the trigger for F172 (PLSH) instruction is in the ON
state. Also, the pulse output can be stopped when the specified target value is matched.
The direction output and output frequency are specified by F172 (PLSH) instruction.
