1.2 Unit Types
1.2.1 FPΣ Control Unit
12k type
Name Number of I/O points Part No. Product No.
Input: 16 points/Transistor output: 16
points NPN
FPG-C32T AFPG2543
Input: 16 points/Transistor output: 16
points NPN
FPG-C32T2 AFPG2643
Input: 16 points/Transistor output: 12
points PNP
FPG-C28P2 AFPG2653
FPΣ Control unit
Input: 16 points/Relay output: 8 points FPG-C24R2 AFPG2423
Input: 16 points/Transistor output: 16
points NPN
FPG-C32TTM AFPG2543TM
Input: 16 points/Transistor output: 16
points NPN
FPG-C32T2TM AFPG2643TM
Input: 16 points/Transistor output: 12
points PNP
FPG-C28P2TM AFPG2653TM
FPΣ Control unit
With thermister input
function
Input: 16 points/Relay output: 8 points FPG-C24R2TM AFPG2423TM
Note) The FPΣ expansion I/O unit cannot be added to FPG-C32T nor FPG-C32TTM FPΣ control unit.
32k type
Name Number of I/O points Part No. Product No.
Input: 16 points/Transistor output: 16
points NPN
FPG-C32TH AFPG2543H
Input: 16 points/Transistor output: 16
points NPN
FPG-C32T2H AFPG2643H
Input: 16 points/Transistor output: 12
points PNP
FPG-C28P2H AFPG2653H
FPΣ Control unit
(High capacity type)
Program capacity: 32k
Input: 16 points/Relay output: 8 points FPG-C24R2H AFPG2423H
Input: 16 points/Transistor output: 16
points NPN
FPG-
C32THTM
AFPG2543HTM
Input: 16 points/Transistor output: 16
points NPN
FPG-
C32T2HTM
AFPG2643HTM
Input: 16 points/Transistor output: 12
points PNP
FPG-
C28P2HTM
AFPG2653HTM
FPΣ Control unit
(High capacity type)
Program capacity: 32k
With thermister input
function
Input: 16 points/Relay output: 8 points
FPG-
C24R2HTM
AFPG2423HTM
Note) The FPΣ expansion I/O unit cannot be added to FPG-C32TH nor FPG-C32THTM FPΣ control unit.
