1-8
1.2.3 FP0 Expansion Unit
The FP0 series expansion I/O unit and intelligent unit can be used on FPΣ.
Expample: <FP0 User’s manual ARCT1F251>
1.2.4 Communication Cassette
Name Description Part No. Product No.
FPΣ Communication
cassette 1-channel
RS232C type
This communication cassette is a 1-channel
unit with a five-wire RS232C port. RS/CS
control is possible.
FPG-COM1 AFPG801
FPΣ Communication
cassette 2-channel
RS232C type
This communication cassette is a 2-channel
unit with a three-wire RS232C port.
Communication with two external devices is
possible.
FPG-COM2 AFPG802
FPΣ Communication
cassette 1-channel
RS485 type
This communication cassette is a 1-channel
unit with a two-wire RS485 port. FPG-COM3 AFPG803
FPΣ Communication
cassette 1-channel
RS485 type & 1-
channel RS232C type
This communication cassette is a 1-channel
unit with a two-wire RS485 port and a 1-
channel unit with a three-wire RS232C port.
FPG-COM4 AFPG806
1.2.5 Related parts
Name Description Product No.
FPΣ battery Necessary for the backup of data registers, etc
or for using the calender function
AFPG804
Cable
length: 1 m
AFP0521 10-wire I/O cable
MIL one-sided socket type
With one-sided wire-press socket
AWG #22 0.3 mm
2
, 2 pcs
Cable
length: 3 m
AFP0523
FPΣ power supply cable Maintenance parts (Packed with
the control unit)
Cable
length: 1 m
AFPG805
FP0 terminal block socket (2 pcs) Maintenance parts (Packed with the relay output
type)
AFP0802
FP2 terminal block socket (2 pcs) Maintenance parts (Packed with the Expansion
I/O unit)
AFP2801
FP0 Wire-press shocket (2 pcs) Maintenance parts (Packed with the Tr type) AFP0807
FP0 mounting plate (slim type) (10
pcs)
Mounting plate to mount FP0 expansion unit on
a panel vertically
AFP0803
FP0 mounting plate (slim 30 type)
(10 pcs)
Mounting plate to mount FPΣ control unit, FPΣ
expansion unit on a panel vertically
AFP0811
FP0 mounting plate (flat type) Mounting plate to mount the control unit on a
panel horizontally
AFP0804
Terminal driver Necessary for the wiring of PHOENIX terminal AFP0806
