7.2 Communication Specifications
Communication Specifications
Computer link
Note1) 9)
General-purpose serial
communication
Note1) 9)
MODBUS RTU
Note1)
1:1
communi-
cation
1:N
communi-
cation
1:1
communi-
cation
1:N
communi-
cation
PC(PLC) link
1:1
communi-
cation
1:N
communi-
cation
Interface RS232C RS485 RS232C RS485
RS232C
Note2)
RS485
RS232C RS485
Target
items
AFPG-801
AFPG-802
AFPG-806
AFPG-803
AFPG-806
AFPG-801
AFPG-802
AFPG-806
AFPG-803
AFPG-806
AFPG-801
AFPG-802
AFPG-803
AFPG-806
AFPG-801
AFPG-802
AFPG-806
AFPG-803
AFPG-806
Commu-
nication
method
Half-
duplex
communi-
cation
Two-wire,
half-duplex
communi-
cation
Half-duplex
communi-
cation
Two-wire,
half-duplex
communi-
cation
Token bus
(Floating
master)
Half-duplex
communi-
cation
Two-wire,
half-duplex
communi-
cation
Note1) Although it has adequate tolerance to noise, it is recommendable to make the user program to
execute retransmission (in order to improve reliability of the communication when a
communication error occurs due to excessive noises or when a receiver equipment cannot
receive data temporarily).
Note2) The number of units of the PC(PLC) link with RS232C is two.
Communication specifications
Item Specifications
Interface RS232C (non-isolated) RS485 (isolated)
Note1) 2)
Communication mode 1:1 communicaion 1:N communication
Communication method Half-duplex communication Two-wire half-duplex communication
Synchronous method Start stop synchronous system
Transmission line Multicore shielded line Shielded twisted-pair cable or VCTF
Transmission distance 15 m Max. 1200 m
Note1) 2)
Baud rate
Note3) Note8)
(to be set by system register)
2400, 4800, 9600, 19200, 38400, 57600, 115200 bps
Computer link ASCII, JIS7, JIS8
General-purpose
serial ommunication
ASCII, JIS7, JIS8, Binary
Trans-
mission
code
MODBUS RTU Binary
Data length 7 bits/8 bits
Parity None/Even/Odd
Stop bit 1 bit/2 bits
Start code STX/No STX
Communication
format
(to be set by
system register)
Note4)
End code CR/CR+LF/None/ETX
No. of connected units
Note5) 6) 7)
2 units
Max. 99 units (Max. 32 units when C-
NET adapter is connected.)
Note1) When connecting a commercially available device that has an RS485 interface, please confirm
operation using the actual device. In some cases, the number of units, transmission distance,
and baud rate vary depending on the connected device.
