7.5.3 Connection with 1:1 Communication (General-purpose serial
communication)
System register settings
Settings for COM1 port (AFPG801, AFPG802)
No. Name Set Value
No. 412 COM1 port selection of communication
mode
General-purpose serial communication
No. 413 Communication format for COM1 port Data length: ……
Parity check: …..
Stop bit: …………
Terminator: ……..
Header: …………
7 bits/8 bits
None/Odd/Even
1 bit/2 bits
CR/CR+LF/None/ETX
No STX/STX
No. 415 Baud rate setting for COM1 port 2400 to 115200 bps
No. 416 Starting address for receive buffer for
COM1 port
DT0 to DT32764 (Initial value: DT0)
No. 417 Receive buffer capacity for COM1 port 0 to 2048 words (Initial value: 2048 words)
Settings for COM2 port (AFPG802, AFPG806)
No. Name Set Value
No. 412 COM2 port selection of communication
mode
General-purpose serial communication
No. 414 Communication format for COM2 port Data length: ……
Parity check: …..
Stop bit: …………
Terminator: ……..
Header: …………
7 bits/8 bits
None/Odd/Even
1 bit/2 bits
CR/CR+LF/None/ETX
No STX/STX
No. 415 Baud rate setting for COM2 port 2400 to 115200 bps
No. 418 Starting address for receive buffer for
COM2 port
DT0 to DT32764 (Initial value: DT2048)
No. 419 Receive buffer capacity for COM2 port 0 to 2048 words (Initial value: 2048 words)
Settings for TOOL port (FPΣ 32k type only)
No. Name Set Value
No. 412 TOOL port selection of communication
mode
General-purpose serial communication
No. 413 Communication format for TOOL port Data length: ……
Parity check: …..
Stop bit: …………
Terminator: ……..
Header: …………
7 bits/8 bits
None/Odd/Even
1 bit/2 bits
CR/CR+LF/None/ETX
No STX/STX
No. 415 Baud rate setting for TOOL port 2400 to 115200 bps
No. 420 Starting address for receive buffer for
TOOL port
DT0 to DT32764 (Initial value: DT0)
No. 421 Receive buffer capacity for TOOL port 0 to 2048 words (Initial value: 0 words)
Note:
The TOOL port becomes the computer link automatically in the PROG. mode even if the general-
purpose serial communication has been set. (It is always possible to communicate with the tool software
such as FPWIN GR in the PROG. mode)
