11-6
11.2.3 Power Supply Specification
FP0 Power Supply Unit (AFP0634)
Item Description
Rated operationg voltage 100-240 V AC
Operating voltage range 85-264 V AC
Rated frequency 50/60 Hz
Operating frequency 47-63 Hz
The number of phase Single phase
Inrush current 30 A(0-p) or less (Cold start)
Leakage current 0.75 mA or less
Input
Holding time 10 ms or more
Reted output 24 V (±5 %) DC
Rated current 0.7A
Operating output current 0-0.7A
Output
Output ripple 500 mV
Over current regulation 0.735 A or more Protection
feature
Over voltage regulation Possible
Life time 20000h ( at 55 °C)
