10-4
Unit’s current consumption table
Control unit
current
consumption
Expansion
unit current
consumption
Input circuit
current
consumption
Output circuit
current
consumption
Unit type
This is the
current
consumed form
the control unit
power supply
connector. If
expansion units
or high-
performance
units are added,
the current is
increased by the
value indicated
below.
This is the
current
consumed from
the expansion
unit power
supply
connector. If a
unit is not listed
below, it means
that it has no
power supply
connector
This is the
current cosumed
by the input
circuits of the
various units.
This value
indicates the
current that flows
into the input
circuit.
This is the current
consumed by the
output circuits of
the various units.
This value
indicates the
current used to
drive the output
circuits. This value
does not include
the load current
value.
FPG-C32
FPG-C28
90mA or less − 77.2mA or less 70mA or less FPΣ
control unit
FPG-C24 160mA or less − 77.2mA or less None
FPΣ
expan-
sion unit
FPG-XY64D2T
FPG-
XY64D2P
35mA or less − 112mA or less 15mA or less
FPG-PP11
FPG-PP21
50mA or less 20mA or less − −
FPG-PP12
FPG-PP22
70mA or less 35mA or less − −
FPG-EM1 35mA or less − − −
FPG-CCLS 40mA or less 40mA or less − −
FPΣ
intelligent
unit
FPG-SL 100mA or less − − −
FP0-E8X 10mA or less 34.4mA or less −
FP0-E8R 15mA or less 50mA or less 17.2mA or less −
FP0-E8YR 10mA or less 100mA or less − −
FP0-E8YT/P 15mA or less − − 24mA or less
FP0-E16X 20mA or less − 68.8mA or less −
FP0-E16R 20mA or less 100mA or less 34.4mA or less −
FP0-E16T/P 25mA or less − 34.4ma or less 24mA or less
FP0-E16YT/P 25mA or less − − 48mA or less
FP0
expan-sion
unit
FP0-E32T/P 40mA or less − 68.8mA or less 48mA or less
FP0-A21 20mA or less 100mA or less − −
FP0-A80 20mA or less 60mA or less − −
FP0-A04V 20mA or less 100mA or less − −
FP0-A04I 20mA or less 130mA or less − −
FP0-TC4/C8 25mA or less − − −
FP0-IOL 30mA or less 40mA or less − −
FP0
intelligent
unit
FP0-CCLS 40mA or less 40mA or less − −
FPG-COM1
FPG-COM2
20mA or less − − −
Communic
ation
cassette
FPG-COM3
FPG-COM4
25mA or less − − −
Display
GT01
AIGT0030
AIGT0032
AIGT0130
AIGT0132
80mA or less − − −
C-NET
adapter S2
AFP15402 50mA or less − − −
