I/O No. of FP0 expansion unit (for right side expansion)
• I/O numbers do not need to be set as I/O allocation is performed automatically by the PLC when an
expansion I/O unit is added.
• The I/O allocation of expansion unit is determined by the installation location.
Unit type Allocation points
Expansion
unit 1
Expansion
unit 2
Expansion
unit 3
FP0-E8X Input: 8 points X20 to X27 X40 to X47 X60 to X67
Input: 4 points X20 to X23 X40 to X43 X60 to X63
FP0-E8R
Output: 4 points Y20 to Y23 Y40 to Y43 Y60 to Y63
FP0-E8YT/P
FP0-E8YR
Output: 8 points Y20 to Y27 Y40 to Y47 Y60 to Y67
FP0-E16X Input: 16 points X20 to X2F X40 to X4F X60 to X6F
Input: 8 points X20 to X27 X40 to X47 X60 to X67 FP0-E16R
FP0-E16T/P
Output: 8 points Y20 to Y27 Y40 to Y47 Y60 to Y67
FP0-E16YT/P Output: 16 points Y20 to Y2F Y40 to Y4F Y60 to Y6F
Input: 16 points X20 to X2F X40 to X4F X60 to X6F
FP0 expansion
unit
FP0-E32T/P
Output: 16 points Y20 to Y2F Y40 to Y4F Y60 to Y6F
Input: 16 points
(ch0)
WX2
(X20 to X2F)
WX4
(X40 to X4F)
WX6
(X60 to X6F)
Input: 16 points
(ch1)
WX3
(X30 to X3F)
WX5
(X50 to X5F)
WX7
(X70 to X7F)
FP0 analog I/O
unit
FP0-A21
Output: 16 points
WY2
(Y20 to Y2F)
WY4
(Y40 to Y4F)
WY6
(Y60 to Y6F)
Input: 16 points
(ch0, 2, 4,6)
WX2
(X20 to X2F)
WX4
(X40 to X4F)
WX6
(X60 to X6F)
FP0 A/D
converter unit
FP0
thermocouple
unit
FP0-A80
FP0-TC4
FP0-TC8
Input: 16 points
(ch1, 3, 5, 7)
WX3
(X30 to X3F)
WX5
(X50 to X5F)
WX7
(X70 to X7F)
Input: 16 points
WX2
(X20 to X2F)
WX4
(X40 to X4F)
WX6
(X60 to X6F)
Input: 16 points
(ch0, 2, 4,6)
WY2
(Y20 to Y2F)
WY4
(Y40 to Y4F)
WY6
(Y60 to Y6F)
FP0 D/A
converter unit
FP0-A04V
FP0-A04I
Input: 16 points
(ch1, 3, 5, 7)
WY3
(Y30 to Y3F)
WY5
(Y50 to Y5F)
WY7
(Y70 to Y7F)
Input: 32 points X20 to X3F X40 to X5F X60 to X7F FP0 I/O link
unit
FP0-IOL
Output: 32 points Y20 to Y3F Y40 to Y5F Y60 to Y7F
• The data of each channel for FP0 A/D conver unit (FP0-A80), FP0 thermocouple unit (FP0-TC4/FP0-
TC8), FP0 D/A converter unit (FP0-A04V/P0-A04I) is switched and read/write using a program that
includes the flag for switching converted data.
• Regarding FP0 CC-Link slave unit, please refer to the exclusive manual.
