12-32
(A: Available, N/A: Not available)
Register
No.
Name Descriptions
Read-
ing
Writ-
ing
DT90194
to
DT90199
Not used -N/AN/A
DT90200
DT90201
High-speed
counter
elapsed value
For
CH2
The elapsed value (32-bit data) for the high-
speed counter is stored here. The value can
be read and written by executing the F1 (DMV)
instruction.
AA
DT90202
DT90203
High-speed
counter target
value
For
CH2
The targe value (32-bit data) of the high-speed
counter specified by the high-speed counter
instruction is stored here. Target values have
been preset for the various instructions, to be
used when the high-speed counter related
instruction F166, F167, F171, F175 or F176 is
executed. The value can be read by executing
F1 (DMV) instruction.
AN/A
DT90204
DT90205
High-speed
counter
elapsed value
For
CH3
The elapsed value (32-bit data) for the high-
speed counter is stored here. The value can
be read and written by executing F1 (DMV)
instruction.
AA
DT90206
DT90207
High-speed
counter target
value
For
CH3
The target value (32-bit data) of the high-
speed counter specified by the high-speed
counter instruction is stored here. Target
values have been preset for the various
instructions, to be used when the high-speed
counter related instruction F166 or F167 is
executed. The value can be read by executing
the F1 (DMV) instruction.
AN/A
DT90208
to
DT90218
Not used N/A N/A
