12-131
Table of Syntax Check Error
Error
code
Name
Opera-
tion
status
Description and steps to take
FP0
FP-e
FP
Σ
FP-X
FP1/FP-M
FP2
FP2SH
FP10SH
FP3
E1
Syntax
error
Stops
A program with a syntax error has been
written.
⇒ Change to PROG. mode and correct
the error.
AAAAAAAAA
E2
(Note)
Duplicated
output
error
Stops
Two or more OT(Out) instructions and
KP(Keep) instructions are programmed
using the same relay.Also occurs when
using the same timer/counter number.
⇒ Change to PROG. mode and correct
the program so that one relay
is not used for two or more OT
instructions,Or, set the duplicated output
to “enable” in system register20. A
timer/counter instructon double definition
error will be detected even if double
output permission has been selected.
AAAAAAAAA
E3
Not paired
error
Stops
For instructions which must be used in a
pair such as jump (JP and LBL), one
instruction is either missing or in an
incorrect position.
⇒ Change to PROG. mode and enter
the two instructions which must
be used in a pair in the correct positions.
AAAAAAAAA
E4
Para-meter
mismatch
error
Stops
An instruction has been written which
does not agree with system register
settings. For example, the number
setting in a program does not agree with
the timer/counter range setting.
⇒ Change to PROG. mode, check the
system register settings, and change so
that the settings and the instruction
agree.
AAAAAAAAA
E5
(Note)
Program
area error
Stops
An instruction which must be written in a
specific area (main program area or
subprogram area) has been written to a
different area (for example, a subroutine
SUB to RET is placed before an ED
instruction).
⇒ Change to PROG. mode and enter
the instruction into the correct area.
AAAAAAAAA
A:Available
Note) This error is also detected if you attempt to execute a rewrite containing a syntax error during RUN.
In this case, nothing will be written to the CPU and operation will continue.
