2-15

Usable thermister

• Thermisters of which resistance values are within a range of 200Ω to 75kΩ.

Manufacturer Thermister type (B constant) Guide for Measuring range (°C)

3390 K -50 to +100 °C

3450 K 50 to +150 °C

4300 K +100 to +200 °C

Shibaura

Electronics Co., Ltd.

5133 K +150 to +300 °C

Note:

• The length of the wiring between the FPΣ control unit and the thermister should be less than 10m.

• A thin wire (AWG28, length: 150 mm) is used for the leader line. Connect and bundle the wire without

any stress.

• It is recommended to mount parts such as condensers externally if the converted value is unstable.
