Input specifications
Item Description
Insulation method Optical coupler
Rated input voltage 24 V DC
Operating voltage range 21.6 to 26.4 V DC
Rated input current Approx. 3.5 mA
Input points per common 32 points/common
(Either the positive or negative of input power supply can be
connected to common terminal.)
Min. on voltage/Min. on current 19.2 V DC/3 mA
Max. off voltage/Max. off current 2.4 V DC/1.3 mA
Input impedance Approx. 6.8 kΩ
off→on 0.2 ms or less
Response time
on→off 0.3 ms or less
Operating mode indicator LED display
Transistor output specifications
Description
Item
NPN PNP
Insulation method Optical coupler
Output type Open collector
Rated load voltage 5 to 24 V DC 24 V CD
Operating load voltage range 4.75 to 26.4 V DC 21.6 to 26.4 V DC
Max. load current 0.1 A
Max. surge current 0.5 A
Output points per common 32 points/common
Off state leakage current 100 μ or less
On state voltage drop 0.5 V or less
off→on 0.2 ms or less
Response time
on→off 0.5 ms or less
Voltage 21.6 to 26.4 V DC
External power
supply for driving
internal circuit
Current 15 mA or less 30 mA or less
Surge absorber Zener diode
Operating mode indicator LED display
Short circuit protection Short circuit prevention, Thermal protection
