FP7 Connector Compatibility
The connectors of old and new model FP7CPU units and add-on cassettes (hereinafter
"cassettes") are shaped differently. Please use old model cassettes with old model units and
new model cassettes with new model units as shown in the table below.
■
Old Model
Type Old Product No.
CPU unit AFP7CPS41ES, AFP7CPS41E, AFP7CPS31ES, AFP7CPS31E, AFP7CPS31S,
AFP7CPS31, AFP7CPS21
Serial Communication
Unit
AFP7NSC
Cassette AFP7CCS1、AFP7CCS2、AFP7CCM1、AFP7CCM2、AFP7CCS1M1、
AFP7CCET1、AFP7FCA21、AFP7FCAD2、AFP7FCTC2
■
New Model
Type New Product No.
CPU unit AFP7CPS4RES, AFP7CPS4RE, AFP7CPS3RES, AFP7CPS3RE, AFP7CPS3RS,
AFP7CPS3R, AFP7CPS2R
Serial Communication
Unit
AFP7NSCR
Cassette AFP7CCRS1、AFP7CCRS2、AFP7CCRM1、AFP7CCRM2、AFP7CCRS1M1、
AFP7CCRET1、AFP7FCRA21、AFP7FCRAD2、AFP7FCRTC2
● Each FP7 unit can be connected to the CPU unit of a new or old model.
● Firmware version upgrades for the CPU unit are available for both new and old models.
● When attaching expansion cassettes to the FP7CPU unit, please use only old models, or only
new models. Trying to attach a combination of old models and new models may cause
damage.
vi
WUME-FP7COM-07
To Next Page
