The settings are registered in the project.
● For details of "PLC link settings", please see the explanation on the next page onward.
6.2.3 List of Setting Items
■
List of setting items (COM.1 settings)
Setting items
Settings when the PLC link
function is used
Remark
Communication
mode
PLC Link
Station no. 1 to 16
Set a specific station no. for PLC to be connected to the
PLC link.
Baud rate 115200 bps
Data length 8 bit
Regardless of settings in FPWIN GR7, the FP7 CPU
unit or SCU itself performs automatic settings.
Parity Odd
Stop bit 1 bit
RS/CS Invalid
Send waiting
time
0
Start code STX Invalid
Terminator
setting
CR
Terminator
judgment time
0
Modem
initialization
Do not initialize
■
List of setting items (PLC link settings)
Setting items Setting range Setting method
Memory block numbers for link
relays and link registers to be used
0 or 1
Specify the device No. range for link relays and link
registers to be used in a block.
Maximum station no. to be used for
PLC link
0 to 16
Set the Max. station no. for PLC to be connected to the
PLC link.
Range of link relays used 0 to 64 words
Specify the device No. range for link relays and link
registers to be used.
Range of link registers used for PLC
link
0 to 128 words
Starting no. for link relay send area 0 to 63
Size of link relay send area 0 to 64 words
Starting No. for link register send
area
0 to 127
6.2 Configuration Required for PLC Link
6-6 WUME-FP7COM-07
