Unit type
Applicable versions
Remark
CPU unit FPWIN GR7
FP7 Serial Communication Unit Ver.1.2 or later Ver.1.3 or later
1.3.5 Restrictions on Consumption Current
Including other units, the consumption current should be within the allowable capacity of a
power supply unit.
■
Unit's consumption current table (24V)
Product name Model number
Consumption current
(mA)
CPU unit
196k steps, Built-in Ethernet
function
AFP7CPS4RE
AFP7CPS4RES
200mA or less
120k steps, Built-in Ethernet
function
AFP7CPS3RE
AFP7CPS3RES
200mA or less
120k steps, No Ethernet function
AFP7CPS3R
AFP7CPS3RS
200mA or less
64k steps, No Ethernet function AFP7CPS2R 150mA or less
When attaching
Extension Cassette
(Communication
Cassette)
to CPU Unit
(Note 1)
(Note 2)
RS-232C x 1ch AFP7CCRS1 35mA or less
RS-232C x 2ch AFP7CCRS2 60mA or less
RS-422 / 485 x 1ch AFP7CCRM1 60mA or less
RS-422 / 485 x 2ch AFP7CCRM2 90mA or less
RS-232C x 1ch
RS-422 / 485 x 1ch
AFP7CCRS1M1 70mA or less
Ethernet AFP7CCRET1 35mA or less
Serial Communication Unit AFP7NSCR 50mA or less
When attaching
Extension Cassette
(Communication
Cassette)
to Serial
Communication
Unit
(Note 1)(Note 2)
RS-232C x 1ch AFP7CCRS1 20mA or less
RS-232C x 2ch AFP7CCRS2 40mA or less
RS-422 / 485 x 1ch AFP7CCRM1 30mA or less
RS-422 / 485 x 2ch AFP7CCRM2 60mA or less
RS-232C x 1ch
RS-422 / 485 x 1ch
AFP7CCRS1M1 50mA or less
(Note 1) The consumption currents listed in the Extension Cassette sections indicate the increased amount of
the CPU's consumption current which increases when each extension cassette is added.
(Note 2) The consumption current of the extension cassette (communication cassette) varies according to the
unit to which the cassette is attached (CPU or serial communication unit).
● For information on the restrictions on the combination of units, also refer to FP7 CPU Unit
User's Manual (Hardware).
1.3 Restrictions on Units Combination
1-10 WUME-FP7COM-07
