9.2 Configuration
9.2.1 Setting Communication Conditions
■
Configuration
Setting items Default Specification range Remark
Communication
mode
MEWTOCOL-COM
General-purpose
communication
Specify "general-purpose communication".
Station no. 1 1 to 999 Settings are not necessary.
Baud rate 9600
300 / 600 / 1200 / 2400 /
4800 / 9600 / 19200 /
38400 / 57600 / 115200 /
230400
The setting must be done according to the
devices connected.
Data length 8 bit 7 bit / 8 bits
Parity Odd None / Odd / Even
Stop bit 1 bit 1 bit / 2 bits
RS/CS Invalid Invalid / Valid
Set to "Valid" only when communication
Cassette AFP7CCRS2 is used in a 5-wire
mode.
Send waiting
time
(unit: 0.01 ms)
0 0 to 10000
Set this when it is necessary to delay
response to the partner device.
Start code STX Invalid Invalid / Valid
The setting must be done according to the
devices connected.
Terminator
setting
CR CR / CR+LF / Time / ETX
Terminator
judgment time
(unit: 0.01 ms)
0
0 to 10000
(0 to 100 ms)
In cases where "Time" is specified in the
terminator setting, set the time for judging
the terminator.
If 0 is set, reception will be completed
after 32 bits worth of time elapses.
Modem
initialization
Do not initialize
Do not initialize / Initialize
while performing
settings / Re-initialize
while performing settings
Perform settings only when a modem is to
be connected. Perform settings for start-
up modem initialization.
(Note 1) In general-purpose communication, the following setting items need not be specified.
Station no., PLC link
9.2 Configuration
WUME-FP7COM-07 9-3
