11.2 Specified Specifications
Event output EV2 Output will be turned ON or OFF depending on the Event conditions
selected in [Event output EV2 allocation].
Relay contact, 1a
Control capacity: 3A 250 V AC (resistive load)
1A 250 V AC (inductive load, cos =0.4)
Electric life: 100,000 cycles
Minimum applicable load: 10 mA 5 V DC
Heating/Cooling
control
When (Heating/Cooling control relay contact output) is selected in
[Event output EV2 allocation], performs Heating/Cooling control.
(Specifications of Heating side are the same as those of OUT1.)
OUT2 proportional band:
Thermocouple, RTD inputs without decimal point: 0 to Input span
Thermocouple, RTD inputs with decimal point: 0.0 to Input span
DC voltage, current inputs: 0.0 to 1000.0%
OUT2 integral time: Same as OUT1 integral time
OUT2 derivative time: Same as OUT1 derivative time
OUT2 proportional cycle: 0.5, or 1 or 120 seconds
Overlap/Dead band setting range:
Thermocouple, RTD inputs: -200.0 to 200.0 ( )
DC voltage, current inputs: -2000 to 2000 (The placement of the decimal
point follows the selection.)
OUT2 ON/OFF hysteresis:
Thermocouple, RTD inputs: 0.1 to 1000.0 ( )
DC voltage, current inputs: 1 to 10000 (The placement of the decimal point
follows the selection.)
OUT2 high limit: 0 to 100%
OUT2 low limit: 0 to 100%
OUT2 cooling method:
One cooling method can be selected from Air cooling (linear
characteristics), Oil cooling (1.5th power of the linear characteristics)
and Water cooling (2nd power of the linear characteristics) by keypad
operation.
Cooling output (OUT2):
Relay contact 1a (EV2)
Control capacity: 3 A 250 V AC (resistive load)
1 A 250 V AC (inductive load, cos =0.4)
Electric life: 100,000 cycles
