4. Wiring
Warning
Turn the power supply to the instrument off before wiring or checking.
Working on or touching the terminal with the power switched on may result in severe injury
or death due to electric shock.
4.1 Terminal Arrangement
KT4R
(Fig. 4.1-1)
KT8R, KT9R
(Fig. 4.1-2)
