4.4.4 Event Output 1, 2
Specifications of Event output 1, 2 are shown below.
Relay contact 1a
Control capacity: 3 A 250 V AC (resistive load)
1 A 250 V AC (inductive load cos =0.4)
Electrical life: 100,000 cycles
Minimum applicable load: 10 mA 5 V DC
KT4R KT8R, KT9R
4.4.5 Serial Communication
Serial communication can be specified only for the KT4R model.
KT4R
