3.2 Panel Cutout (Scale: mm)
Caution
If lateral close mounting is used for the unit, IP66 specification (Water-proof/Dust-proof)
may be compromised, and all warranties will be invalidated.
KT4R
Lateral close mounting
n: Number of units mounted
(Fig. 3.2-1)
KT8R
Lateral close mounting
n: Number of units mounted
(Fig. 3.2-2)
KT9R
Lateral close mounting
n: Number of units mounted
(Fig. 3.2-3)
130
92
＋0.8
0
45
＋0.5
0
n×48-3
＋0.5
0
92
＋0.8
0
□92
＋0.8
0
130
n×96-3
＋0.5
0
92
＋0.8
0
