8.4 Performing Fixed Value Control
Fixed value control is a typical temperature control action, which reduces deviation
from a single SV by comparing with PV.
To perform Fixed value control, set the SV.
There are 2 ways to set the SV.
• Set the SV in [SV1] in Initial setting mode.
• Set the SV in [SV1] in Main setting mode.
Setting item [SV1] in Initial setting mode corresponds to [SV1] in Main setting mode.
Therefore, if one SV1 is changed, the other SV1 will also be changed.
Factory default value is 0 (zero).
(Example) Setting SV to 100
Power ON
RUN mode
PV/SV Display
Main setting mode
SV1 [10]
or
Set SV to 100 .
(Many times) or (3 sec)
RUN mode
PV/SV Display
Now, settings are complete.
