11. Specifications
11.1 Standard Specifications
Rating
Input Scale Range Resolution
-200 to 1370 -328 to 2498 1 ( )
K
-200.0 to 400.0 -328.0 to 752.0 0.1 ( )
J -200 to 1000 -328 to 1832 1 ( )
R 0 to 1760 32 to 3200 1 ( )
S 0 to 1760 32 to 3200 1 ( )
B 0 to 1820 32 to 3308 1 ( )
E -200 to 800 -328 to 1472 1 ( )
T -200.0 to 400.0 -328.0 to 752.0 0.1 ( )
N -200 to 1300 -328 to 2372 1 ( )
PL- 0 to 1390 32 to 2534 1 ( )
C(W/Re5-26) 0 to 2315 32 to 4199 1 ( )
-200.0 to 850.0 -328.0 to 1562.0 0.1 ( )
Pt100
-200 to 850 -328 to 1562 1 ( )
-200.0 to 500.0 -328.0 to 932.0 0.1 ( )
JPt100
-200 to 500 -328 to 932 1 ( )
4 to 20 mA -2000 to 10000 (*) 1
0 to 20 mA -2000 to 10000 (*) 1
0 to 1 V -2000 to 10000 (*) 1
0 to 5 V -2000 to 10000 (*) 1
1 to 5 V -2000 to 10000 (*) 1
0 to 10 V -2000 to 10000 (*) 1
Rated scale
(*) Scaling and decimal point place selection are possible.
Thermocouple K, J, R, S, B, E, T, N, PL- , C(W/Re5-26)
External resistance: 100 max.
However, for B input, External resistance: 40 max.
RTD
Pt100, JPt100 3-wire type
Allowable input lead wire resistance: 10 max. per wire
Direct current
0 to 20 mA DC, 4 to 20 mA DC
Input impedance: 50
Allowable input current: 50 mA max.
0 to 1 V DC
Input impedance: 1 M min.
Allowable input voltage: 5 V DC max.
Allowable signal source resistance: 2 k max.
Input
DC voltage
0 to 5 V DC, 1 to 5 V DC, 0 to 10 V DC
Input impedance: 100 k min.
Allowable input voltage: 15 V DC max.
Allowable signal source resistance: 100 max.
Power
supply
voltage
100 to 240 V AC 50/60 Hz
24 V AC/DC 50/60 Hz (24 V AC/DC can be specified only for the KT4R model.)
Allowable
voltage
