6. Initial Settings
Setup (setting the Input type, Event output allocation, SV, etc.) should be done before using this
controller, according to the user’s conditions.
Perform setup in Initial setting mode.
Setting items in Initial setting mode are shown in (Table 6.1).
If the user’s specification is the same as the factory default value of this instrument, or if user’s
instrument has already been installed in a system, initial settings are not necessary.
Proceed to Section ‘7. Settings’ (p.42).
(Table 6.1)
Setting Items in Initial Setting Mode Factory Default
Input type K -200 to 1370
Scaling high limit 1370
Scaling low limit -200
Decimal point place No decimal point
Event output EV1 allocation No event
EV1 alarm value 0 Enabled/Disabled Disabled
EV1 alarm value 0
EV1 high limit alarm value 0
EV1 alarm hysteresis 1.0
EV1 alarm delay time 0 sec
EV1 alarm Energized/De-energized Energized
Event output EV2 allocation No event
EV2 alarm value 0 Enabled/Disabled Disabled
EV2 alarm value 0
EV2 high limit alarm value 0
EV2 alarm hysteresis 1.0
EV2 alarm delay time 0 sec
EV2 alarm Energized/De-energized Energized
Loop break alarm time 0 minutes
Loop break alarm span 0
SV1 0
