When using terminal covers (sold separately), make sure the longer side is on the back right and left
sides of the case.
Pass the wires from terminals 13 to 24 through between covers.
(Fig. 4.3-3)
(Fig. 4.3-4) (Fig. 4.3-5)
2 terminal covers
Mount the longer side of the
cover to the back right and
left.
Top of KT9R
