Characters,
Factory Default
Setting Item, Function, Setting Range
[13] SV2
• Sets SV2.
• Corresponds to [SV2] in Initial setting mode.
If Program control is selected in [OUT/OFF key function], this will become Step 2
SV.
• Setting range: Scaling low limit to Scaling high limit (*1)
Available only when Program control is selected in [OUT/OFF key function].
[14]
Step 2 time
• Sets Step 2 time.
• Setting range: , or 00:00 to 99:59
If is set, Step 2 time will be held, and Fixed value control will be performed
using Step 2 SV.
Available only when Program control is selected in [OUT/OFF key function].
[15] Step 2 wait value
• Sets Step 2 wait value.
• Setting range: 0 to Converted value of 20% of the input span
DC voltage, current inputs: 0 to Converted value of 20% of scaling span (*1)
Setting the value to 0 disables Wait function.
Available only when Program control is selected in [OUT/OFF key function].
[16] SV3
• Sets SV3.
• Corresponds to [SV3] in Initial setting mode.
If Program control is selected in [OUT/OFF key function], this will become Step 3
SV.
• Setting range: Scaling low limit to Scaling high limit (*1)
Available only when Program control is selected in [OUT/OFF key function].
[17]
Step 3 time
• Sets Step 3 time.
• Setting range: , or 00:00 to 99:59
If is set, Step 3 time will be held, and Fixed value control will be performed
using Step 3 SV.
Available only when Program control is selected in [OUT/OFF key function].
[18] Step 3 wait value
• Sets Step 3 wait value.
• Setting range: 0 to Converted value of 20% of the input span
DC voltage, current inputs: 0 to Converted value of 20% of scaling span (*1)
Setting the value to 0 disables Wait function.
Available only when Program control is selected in [OUT/OFF key function].
(*1) The placement of the decimal point follows the selection.
