Panasonic KV-S1057C - Kv-Sl1066

169
14.10.4. KV-SL1066
Safety Ref.
No.
Part No. Part Name & Description Remarks
(ICs)
IC2 C0ZBZ0002269 IC
IC3 C0ZBZ0002269 IC
IC4 C1ZBZ0005360 IC
IC5 It is impossible to replace IC5 by
itself. To replace IC5 replace the
CONTROL Board assembly.
IC6 C0EBY0000664 IC
IC7 C0FBBY000001 IC
IC8 PNWIS1570M IC
IC9 C0DBAYY02336 IC
IC10 C0DBAYY02335 IC
IC11 C0DBAYY01820 IC
IC12 C0DBAYY02336 IC
IC14 C0DBGYY03749 IC
IC17 C0DBGYY02061 IC
IC18 AN44066B-VF IC
IC19 C0GBY0000103 IC
IC20 C3ABTY000118 IC
IC21 C3ABTY000118
IC
IC22 C0ABBB000184 IC
IC23 C0ABEB000111 IC
IC25 B0ZBZ0000178 IC
IC30 C1ZBZ0005369 IC
IC36 C3BBJY000016 IC
IC37 C3BBJY000016 IC
IC42 C0ABBA000093 IC
IC43 C1ZBZ0004892 IC
IC47 C0JBAE000285 IC
IC48 C0CBCAG00031 IC
IC49 C0DBGYY02036 IC
IC50 C0JBAZ001966 IC
IC51 C0CBCBG00019 IC
IC52 C0CBCBG00019 IC
IC53 C0DBAYY01820 IC
IC54 C0JBAZ001966 IC
IC55 C0JBAZ001966
IC
(TRANSISTORS)
Q1 DRC9124E0L TRANSISTOR(SI)
Q2 DRC9124E0L TRANSISTOR(SI)
Q3 DRC9124E0L TRANSISTOR(SI)
Q4 DRC9124E0L TRANSISTOR(SI)
Q5 DRC9124E0L TRANSISTOR(SI)
Q6 DRC9124E0L TRANSISTOR(SI)
Q7 DSC7003S0L TRANSISTOR(SI)
Q8 DSC7003S0L TRANSISTOR(SI)
Q9 DSC7003S0L TRANSISTOR(SI)
Q10 DSC7003S0L TRANSISTOR(SI)
Q11 DSC7003S0L TRANSISTOR(SI)
Q12 DSC7003S0L
TRANSISTOR(SI)
Q13 B1ADCF000001 TRANSISTOR(SI)
Q14 B1ABCF000011 TRANSISTOR(SI)
Q15 DRA9114E0L TRANSISTOR(SI)
Q16 B1ABCF000011 TRANSISTOR(SI)
Q17 B1CHRE000013 TRANSISTOR(SI)
Q20 DRC9144E0L TRANSISTOR(SI)
Q21 B1CHQC000015 TRANSISTOR(SI)
Q22 DRC9124E0L TRANSISTOR(SI)
Q25 B1ABCF000011 TRANSISTOR(SI)
Q27 IMX1 TRANSISTOR(SI) S
Q28 B1ABCF000011 TRANSISTOR(SI)
Q29 IMX1 TRANSISTOR(SI) S
Q30 B1HFCFA00003 TRANSISTOR(SI)
Q31 B1HFCFA00003 TRANSISTOR(SI)
Q32 DRC9124E0L TRANSISTOR(SI)
Q33 B1ABCF000011 TRANSISTOR(SI)
Q34 B1ABCF000011 TRANSISTOR(SI)
Q35 B1ABCF000011 TRANSISTOR(SI)
Q36 B1CHRE000013 TRANSISTOR(SI)
Q37 DRC9144E0L TRANSISTOR(SI)
Q38 DRC9124E0L TRANSISTOR(SI)
Q39 DRC9144E0L TRANSISTOR(SI)
Q40 DRC9124E0L TRANSISTOR(SI)
Q41 B1ADGE000012 TRANSISTOR(SI)
Q42 DRC9124E0L TRANSISTOR(SI)
Q43 B1ABCF000011 TRANSISTOR(SI)
(DIODES)
D1 DA2J10100L DIODE(SI)
D2 DA2J10100L DIODE(SI)
D3 DA2J10100L DIODE(SI)
D4 DZ2J13000L DIODE(SI)
D5 DA2J10100L DIODE(SI)
D6 DA2J10100L DIODE(SI)
D9 DA2J10100L DIODE(SI)
D10 DA2J10100L DIODE(SI)
D11 DA2J10100L DIODE(SI)
D12 DZ2J13000L DIODE(SI)
D13 DZ2J03900L DIODE(SI)
D16 DZ2J02400L DIODE(SI)
D17 DZ2J27000L DIODE(SI)
D19 DA2J10100L DIODE(SI)
D20 DZ2J082M0L DIODE(SI)
D21 DA2J10100L DIODE(SI)
D22 DA2J10100L DIODE(SI)
D23 DA2J10100L DIODE(SI)
D24 DA2J10400L DIODE(SI)
D31 DZ2J05600L
DIODE(SI)
D38 DB3X315E0L DIODE(SI)
D40 PQVDRB751V4 DIODE(SI) S
D47 DA2J10100L DIODE(SI)
D48 DA2J10100L DIODE(SI)
(RESISTORS)
R8 ERJ2GEJ473 47k
R9 ERJ3GEY0R00 0
R10 ERJ3GEY0R00 0
R11 ERJ3GEY0R00 0
R12 ERJ3GEY0R00 0
R13 ERJ3GEY0R00 0
R14 ERJ3GEY0R00 0
R23 ERJ2GEJ470 47
R24 ERJ2GEJ470 47
R25 ERJ2GEJ470 47
R26 ERJ2GEJ470 47
R27 ERJ2GEJ470 47
R28 ERJ2GEJ470 47
R73 ERJ3GEY0R00 0
R78 ERJ3GEYJ122 1.2k
R79 ERJ3GEYJ122 1.2k
R80 ERJ3GEYJ122 1.2k
R81 ERJ3GEYJ122 1.2k
R82 ERJ3GEYJ122 1.2k
R83 ERJ3GEYJ122 1.2k
R84 PQ4R10XJ101 100 S
R85 PQ4R10XJ101 100 S
R86 PQ4R10XJ101
100 S
R87 PQ4R10XJ101 100 S
R88 PQ4R10XJ101 100 S
R89 PQ4R10XJ101 100 S
R90 PQ4R10XJ101 100 S
R91 PQ4R10XJ101 100 S
R92 PQ4R10XJ101 100 S
R93 PQ4R10XJ101 100 S
R94 PQ4R10XJ101 100 S
R95 PQ4R10XJ101 100 S
R96 ERJ2GEJ220 22
R97 ERJ2GEJ220 22
R98 ERJ2GEJ220 22
R99 ERJ2GEJ220 22
R100 ERJ2GEJ220
22
R101 ERJ2GEJ473 47k
R102 ERJ2GEJ220 22
R103 ERJ2GEJ220 22
R104 ERJ2GEJ220 22
