Panasonic KV-S1057C - Error Codes

44
9.3.2. Error Codes
Classification and Error codes are as follows. Troubleshooting for these error messages and codes is shown in Sec.Troubleshoot-
ing-2 (when an error message is displayed on PC) (P.60).
Fig. 9.3.2.1 Classification Code Outline
Fig. 9.3.2.2 Error Code Outline
Fig.9.3.2.3 Error Code
Classifica-
tion Code
Contents Classifica-
tion Code
Contents Classifica-
tion Code
Contents
U1- Document H1-
— F1- Hardware (SDRAM)
U2- Document H2-
— F2- Hardware (RAM)
U3- Door H3-
— F3- Hardware
(Analog IC etc.)
U4-
— H4- — F4- Home Position
U5-
— H5- — F5- Paper Sensor
U6-
— H6- — F6- Scanning
U7-
— H7- — F7- Guide, Board
U8-
— H8- — F8- Others (Sensor)
U9-
— H9- — F9- Hardware (Processor)
ST1 Error Contents
0x Communication error
1x Paper jam error
2x Door open error
3x Mechanical function error
4x Paper sensor error
5x Scanning error
6x Other sensor error
7x
—
8x Hardware error
9x Hardware error
ax —
bx —
cx —
dx —
ex —
fx —
Classifi-
cation
Code
Error Code Contents
ST1 ST2 ST3 ST4
- 00000000No error
- 0a 00 00 00 Stop by clicking “STOP”
- 0b 00 00 00 Stop by using ADF stop-command
U11 11 00 00 00 Paper feed jam: Paper didn’t reach the Starting Sensor.
U12 12 x 00 00 Conveyor jam: Paper jammed around the Starting Sensor.
(ST2: 0 Minimum document length / :1 Short interval between docu-
ment)
U16 16 00 00 00 Paper exit jam: The scanned paper was not ejected within the period
predetermined by this scanner.
U18 18 00 00 00 Document remains in scanner
U23 1c 00 03 00 Double feed error
U30 20 00 00 00 Door open error
F19 89 00 00 00 DRAM error
F31 95 x 00 00 Analog IC error (ST2:0 Front /:1 Back)
F34 98 00 00 00 EEPROM error
F60 50 00 00 00 Front-side gain adjustment error
F61 51 00 00 00 Front-side black-level adjustment error
F62 52 00 00 00 Back-side gain adjustment error
F63 53 00 00 00 Back-side black-level adjustment error
