CN01 CIS(F)
1 16 FLEDR Cathode for LED (Red)
2 15 FLEDG Cathode for LED (Green)
3 14 FLEDB Cathode for LED (Blue)
4 13 VLED Power for LED (Common Anode)
5 12 FCLK Pixel clock
6 11 GND Ground
7 10 FSP Start Image
8 9 MODE Resolution control
9 8 FVREF CIS Reference Voltage
10 7 +3.3V Power Supply for CIS
11 6 GND Ground
12 5 FCIS2 Pixel data 2
13 4 GND Ground
14 3 FCIS1 Pixel data 1
15 2 GND Ground
16 1 FCIS0 Pixel data 0
CN01 [ CONTROL BOARD ] - CIS(Front) KV-S1057C/KV-SL1066
CN01 CIS(F)
1 22 FLEDR Cathode for LED (Red)
2 21 FLEDG Cathode for LED (Green)
3 20 FLEDB Cathode for LED (Blue)
4 19 VLED Power for LED (Common Anode)
5 18 FCLK Pixel clock
6 17 GND Ground
7 16 FSP Start Image
8 15 MODE Resolution control
9 14 FVREF CIS Reference Voltage
10 13 +3.3V Power Supply for CIS
11 12 GND Ground
12 11 FCIS5 Pixel data 5
13 10 GND Ground
14 9 FCIS4 Pixel data 4
15 8 GND Ground
16 7 FCIS3 Pixel data 3
17 6 GND Ground
18 5 FCIS2 Pixel data 2
19 4 GND Ground
20 3 FCIS1 Pixel data 1
21 2 GND Ground
22 1 FCIS0 Pixel data 0
CN02 CIS(B)
16 16 BLEDR Cathode for LED (Red)
15 15 BLEDG Cathode for LED (Green)
14 14 BLEDB Cathode for LED (Blue)
13 13 VLED Power for LED (Common Anode)
12 12 BCLK Pixel clock
11 11 GND Ground
10 10 BSP Start Image
9 9 MODE Resolution control
8 8 BVREF CIS Reference Voltage
7 7 VCC Power Supply for CIS
6 6 GND Ground
5 5 BCIS2 Pixel data 2
4 4 GND Ground
3 3 BCIS1 Pixel data 1
2 2 GND Ground
1 1 BCIS0 Pixel data 0
