Panasonic KV-S1057C - LCD PANEL Board; PANEL SWITCH Board; PANEL Board (KV-Sl10 Xx ONLY)

178
14.11. LCD PANEL Board
14.12. PANEL SWITCH Board
14.13. PANEL Board
(KV-SL10xx ONLY)
Safety Ref.
No.
Part No. Part Name & Description Remarks
(IC)
IC4000 C1ZBZ0004019 IC
(TRANSISTOR)
Q4000 B1GBCFEN0010 TRANSISTOR(SI) S
(DIODES)
D4000 B3AFB0000370 DIODE(SI)
D4001 B3ABA0000942 DIODE(SI)
D4002 B3AAA0001216 DIODE(SI)
(RESISTORS)
R4001 ERJ3GEYJ473 47k
R4008 ERJ3GEYJ151 150
R4009 ERJ3GEYJ181 180
R4010 ERJ3GEYJ181 180
R4019 ERJ3GEYJ473 47k
R4020 ERJ3GEYJ102 1k
R4021 ERJ3GEY0R00 0
R4022 ERJ3GEY0R00 0
R4023 ERJ3GEY0R00 0
R4024 ERJ3GEY0R00
0
R4025 ERJ3GEYJ101 100
R4026 ERJ3GEYJ101 100
R4027 ERJ3GEYJ101 100
R4028 ERJ3GEYJ101 100
R4029 ERJ3GEYJ101 100
R4030 ERJ3GEYJ332 3.3k
R4031 ERJ3GEY0R00 0
(CAPACITORS)
C4002 ECUV1C104KBV 0.1 S
C4003 ECUV1C104KBV 0.1 S
C4004 ECUV1H561KBV 560p
C4005 ECUV1H561KBV 560p
C4007 ECUV1H561KBV 560p
C4008 ECUV1H151JCV 150p
C4009 ECUV1H102KBV 0.001
C4010 F1H1E1050001
1
C4012 F1H1E1050001 1
C4013 ECUV1H391JCV 390p
C4014 ECJ1VC1H101J 100p
C4015 ECUV1C104KBV 0.1 S
C4016 ECUV1H101JCV 100p
C4017 ECUV1H101JCV 100p
(CONNECTORS )
CN4000 K1MY10BA0516 CONNECTOR
CN4002 K1KY10BA0094 CONNECTOR
(SWITCHE)
SW4007 K0H1BA000259 SPECIAL SWITCH
(OTHERS)
LS4000 LH-5S-1.5 SPACER
LS4001 LH-5S-1.5 SPACER
Safety Ref.
No.
Part No. Part Name & Description Remarks
(RESISTORS)
R4100 ERJ3GEYJ181 180
R4101 ERJ3GEYJ181 180
R4102 ERJ3GEYJ181
180
R4103 ERJ3GEYJ181 180
R4104 ERJ3GEYJ181 180
R4105 ERJ3GEYJ181 180
R4106 ERJ3GEYJ181 180
(CONNECTOR)
CN4100 K1KY10BA0093 CONNECTOR
(SWITCHES)
SW4100 K0H1BA000259 SPECIAL SWITCH
SW4101 K0H1BA000259 SPECIAL SWITCH
SW4102 K0H1BA000259 SPECIAL SWITCH
SW4103 K0H1BA000259 SPECIAL SWITCH
SW4104 K0H1BA000259 SPECIAL SWITCH
SW4105 K0H1BA000259 SPECIAL SWITCH
SW4106 K0H1BA000259 SPECIAL SWITCH
Safety Ref.
No.
Part No. Part Name & Description Remarks
(IC)
IC5000 C1ZBZ0004019 IC
(DIODES)
D5000 B3ABA0000942 DIODE(SI)
D5001 B3AAA0001216 DIODE(SI)
D5002 B3BB1Y000013 DIODE(SI)
(RESISTORS)
R5000 ERJ3GEYJ473 47k
R5008 ERJ3GEYJ151 150
R5009 ERJ3GEYJ151 150
R5010 ERJ3GEYJ151 150
R5011 ERJ3GEYJ151 150
R5012 ERJ3GEYJ181 180
R5013 ERJ3GEYJ181 180
R5014 ERJ3GEYJ151
150
R5015 ERJ3GEYJ151 150
R5016 ERJ3GEYJ151 150
R5017 ERJ3GEYJ181 180
R5018 ERJ3GEYJ181 180
R5019 ERJ3GEYJ181 180
R5020 ERJ3GEYJ181 180
R5022 ERJ3GEYJ102 1k
R5023 ERJ3GEYJ101 100
R5024 ERJ3GEYJ101 100
R5025 ERJ3GEYJ101 100
R5026 ERJ3GEYJ101 100
R5027 ERJ3GEYJ332 3.3k
R5028 ERJ3GEY0R00 0
R5100 ERJ3GEY0R00 0
R5101 ERJ8GEY0R00 0
R5102 ERJ3GEY0R00 0
R5103 ERJ8GEY0R00 0
R5104 ERJ3GEY0R00 0
R5105 ERJ3GEY0R00 0
R5106 ERJ8GEY0R00 0
R5107 ERJ3GEY0R00 0
R5108 ERJ8GEY0R00 0
R5109 ERJ8GEY0R00 0
R5110 ERJ8GEY0R00 0
(CAPACITORS)
C5002 ECUV1C104KBV 0.1 S
C5003 ECUV1C104KBV 0.1 S
C5004 ECUV1H561KBV 560p
C5005 ECUV1H561KBV 560p
C5006 ECUV1H561KBV 560p
C5007 ECUV1H151JCV 150p
C5008 ECUV1H102KBV 0.001
C5010 ECUV1H391JCV 390p
C5011 ECJ1VC1H101J 100p
C5012 ECUV1C104KBV 0.1 S
C5013 ECUV1H101JCV 100p
C5014 ECUV1H101JCV 100p
(CONNECTOR)
CN5000 K1MY10BA0516 CONNECTOR
(SWITCHES)
SW5000 K0H1BA000259 SPECIAL SWITCH
SW5001 K0H1BA000259 SPECIAL SWITCH
SW5002 K0H1BA000259 SPECIAL SWITCH
SW5003 K0H1BA000259 SPECIAL SWITCH
SW5004 K0H1BA000259 SPECIAL SWITCH
(OTHERS)
LS5000 LH-5S-1.5 SPACER
LS5001 LH-5S-1.5 SPACER
Safety Ref.
No.
Part No. Part Name & Description Remarks
