Panasonic KX-TDA30 - Page 156

2.8 Connection of DECT Portable Stations — KX-TDA100/KX-TDA200
156 Installation Manual
For the KX-TDA0142CE User only:
3. Wrap the cable once around the ferrite core. Then close the case of the ferrite core.
Note
If you need to open the ferrite core, use a flathead screwdriver to unlatch the case of the
ferrite core.
To CSIF card
