EVOHD+ Installation Guide
79
Programmable Output Options
PGM State
SECTION [006]: OPTION [1]
NOTE: The PGM can provide 50mA to any device connected to it.
PGM Deactivation Mode
SECTION [006]: OPTION [2]
PGM Base Time
SECTION [006]: OPTION [3]
PGM Override
SECTION [006]: OPTION [4]
When the PGM override is enabled, the keypad's on-board PGM will ignore PGM Activation Events (section ), PGM Deactivation Events (section ), and PGM Timers
(section ). It will remain in its normal state until the PGM Override is disabled. This option may be used to test the PGM connections.
PGM Timer
SECTION [008]
The value programmed in section [008] represents how long the PGM will remain in its opposite state after being activated. To program the timer, enter a 3-digit
decimal value (000 to 255) in section [008]. Default: 5 seconds.
PGM Activation Event
SECTIONS [009] TO [012]
Enter the sections that correspond to the Event Group, Feature Group, Start # and End # of the PGM and enter the required data.
PGM Deactivation Event
SECTIONS [013] TO [016]
If the PGM Deactivation Option is set to follow the PGM Deactivation event, the PGM will return to its normal state when the event programmed in sections [013] to
[016] occurs.
Enter the sections that correspond to the Event Group, Feature Group, Start # and End # of the PGM and enter the required data.
K641R Programming
Partition Assignment
SECTION [001]: OPTIONS [1] TO [8]
To assign the keypad to a partition, enable the option that corresponds to the desired partition. By default, partitions 1 to 8 are enabled.
Display Access Code Entry
SECTION [003]: OPTION [1]
Option [1] OFF=Digits are replaced by a “*“(default)
Option [1] ON=Access Code digits will be displayed
Display Exit Delay Timer
SECTION [003]: OPTION [2]
Option [2] OFF=Will not display Exit Delay timer (default)
Option [2] ON=LCD screen will display Exit Delay timer
Option [1] OFF = PGM is Normally Open (default)
Option [1] ON = PGM is Normally Closed
Option [2] OFF = Deactivates on PGM Deactivation Event (default)
Option [2] ON = PGM will deactivate according to the PGM Timer
Option [3] OFF = PGM Base Time is 1 second (default)
Option [3] ON = PGM Base Time is 1 minute
Option [4] OFF = PGM Override disabled (default)
Option [4] ON = PGM Override enabled
Event Group Feature Group Start # End #
PGM
[009] [010] [011] [012]
Event Group Feature Group Start # End #
PGM
[013] [014] [015] [016]
