DOC-0017-03-EN: AC15 Series - Hardware Installation Manual
DOC-0017-03-EN-B 04.04.2023 23 (125)
Terminal Block Wire Range (Europe)
Wire sizes for Europe should be chosen with respect to the inverter operating conditions, in addition to local
National Electrical Safety Installation Requirements. Local wiring regulations always take precedence.
230V Products:
Frame
Size
AC Line Input
Terminals
(L1/L, L2/N,
L3)
DC Link /
Brake Output
Terminals
(DC+, DC-,
DBR)
Motor Output
Terminals
(U, V, W)
Earth
Terminal
(PE)
Chassis Earth
Clamp
(PE)
1
0.5 – 2.5
M4 Fork Crimp
2
1.5 – 4.0
M4 Fork Crimp
3
4.0 – 10.0
M4 Fork Crimp
4
0.5 – 10.0
M4 Fork Crimp
5
0.5 – 35.0
M4 Fork Crimp
All cable size ranges specified in mm
2
400V Products:
Frame
Size
AC Line Input
Terminals
(L1/L, L2/N,
L3)
DC Link /
Brake Output
Terminals
(DC+, DC-,
DBR)
Motor Output
Terminals
(U, V, W)
Earth
Terminal
(PE)
Chassis Earth
Clamp
(PE)
1
1.5 – 4.0
M4 Fork Crimp
2
1.5 – 4.0
M4 Fork Crimp
3
4.0 – 10.0
M4 Fork Crimp
4
0.5 – 10.0
M4 Fork Crimp
5
0.5 – 35.0
M5 Fork Crimp
All cable size ranges specified in mm
2
Terminal Block Wire Range (North America)
North American wire sizes (AWG) are based on NEC/NFPA-70 for ampacities of thermoplastic-insulated
(75ºC) copper conductors.
The wire sizes allow for an ampacity of 125% of the rated input and output amperes for motor branch-circuit
conductors as specified in NEC/NFPA-70.
1ø, 230V Products:
Frame
Size Product Code
Motor
Power
(kW)
AC Line Input
Terminals
(L1/L, L2/N, L3)
Brake Output
Terminals
(DC+, DBR)
Motor Output
Terminals
(U, V, W)
1
Terminal Block Wire Range: 12 – 26 AWG
15G-11-0025...
0.37
14
14
14
15G-11-0045...
0.75
14
14
14
15G-11-0070...
1.5
14
14
14
2
Terminal Block Wire Range: 10 – 26 AWG
15G-12-0100...
2.2
10
14
10
All cable sizes specified in AWG
