Parker AC15 Series User Manual

DOC-0017-03-EN: AC15 Series - Hardware Installation Manual
24 (125) DOC-0017-03-EN-B 04.04.2023
3ø, 230V Products:
Frame
Size Product Code
Motor
Power
(kW)
AC Line Input
Terminals
(L1/L, L2/N, L3)
DC Link / Brake
Output
Terminals
(DC+, DC-, DBR)
Motor Output
Terminals
(U, V, W)
1
Terminal Block Wire Range: 12 – 26 AWG
15G-31-0025...
0.37
14
14
14
15G-31-0045...
0.75
14
14
14
15G-31-0070...
1.5
14
14
14
2
Terminal Block Wire Range: 10 – 26 AWG
15G-32-0100...
2.2
14
14
14
3
Terminal Block Wire Range: 10 – 20 AWG
15G-33-0170...
4.0
10
14
10
4
Terminal Block Wire Range: 6 – 20 AWG
15G-34-0210...
5.5
10
14
10
5
Terminal Block Wire Range: 2 – 20 AWG
15G-35-0300...
7.5
8
12
8
15G-35-0400...
11
8
10
8
All cable sizes specified in AWG
3ø, 400V Products:
Frame
Size
Product Code
Motor
Power
(kW)
AC Line Input
Terminals
(L1/L, L2/N, L3)
DC Link / Brake
Output
Terminals
(DC+, DC-, DBR)
Motor Output
Terminals
(U, V, W)
1
Terminal Block Wire Range: 10 – 30 AWG
15G-41-0012…
0.37
14
14
14
15G-41-0020...
0.75
14
14
14
15G-41-0040...
1.5
14
14
14
2
Terminal Block Wire Range: 10 – 30 AWG
15G-42-0065...
2.2
14
14
14
15G-42-0090...
4.0
14
14
14
3
Terminal Block Wire Range: 10 – 20 AWG
15G-43-0120...
5.5
12
14
14
15G-43-0170...
7.5
10
14
10
4
Terminal Block Wire Range: 6 – 20 AWG
15G-44-0230...
11
10
14
10
15G-44-0320...
15
8
14
8
5
Terminal Block Wire Range: 2 – 20 AWG
15G-45-0380…
18.5
6
10
8
15G-45-0440…
22
6
10
6
15G-45-0600…
30
3
8
4
All cable sizes specified in AWG
