Parker AC15 Series User Manual

DOC-0017-03-EN: AC15 Series - Hardware Installation Manual
DOC-0017-03-EN-B 04.04.2023 25 (125)
Terminal Block Tightening Torques
230V Products:
Frame
Size
AC Line Input
Terminals
(L1/L, L2/N,
L3)
DC Link /
Brake Output
Terminals
(DC+, DC-,
DBR)
Motor Output
Terminals
(U, V, W)
Earth
Terminal
(PE)
Chassis Earth
Clamp
(PE)
1
0.4 (3.5)
1.8 (16.0)
2
1.10 (9.7)
1.8 (16.0)
3
1.26 (11.2)
1.8 (16.0)
4
2.15 (19.0)
1.8 (16.0)
5
4.1 (36.3)
1.8 (16.0)
All torques are maximum values specified in Nm (lb-in)
400V Products:
Frame
Size
AC Line Input
Terminals
(L1/L, L2/N,
L3)
DC Link /
Brake Output
Terminals
(DC+, DC-,
DBR)
Motor Output
Terminals
(U, V, W)
Earth
Terminal
(PE)
Chassis Earth
Clamp
(PE)
1
1.13 (10.0)
1.8 (16.0)
2
1.13 (10.0)
1.8 (16.0)
3
1.26 (11.2)
1.8 (16.0)
4
2.15 (19.0)
1.8 (16.0)
5
4.1 (36.3)
3.6 (32.0)
All torques are maximum values specified in Nm (lb-in)
